Yamaha RX-V6A 7.2 Channel 8K A/V Receiver

by Yamaha
UPC: 27108959009
Call for Availability
$749.95

SKU RX-V6A

Product Qualifies for FREE Ground Shipping

Yamaha RX-V6A 7.2 Channel 8K A/V Receiver

This 7.2-channel, 100 Watt AV receiver boldly explores entertainment possibilities for an advanced home theater with the latest in video and audio, including Dolby Atmos Height Virtualization, DTS:X, wireless streaming and more.

  • 7.2-channel 100 Watt surround sound with Zone 2
  • 8K/60Hz and 4K/120Hz HDMI (with future firmware update) with HDCP 2.3 and eARC (7 in/1 out)
  • Supports enhanced media and gaming - ALLM, VRR, QFT, QMS (with future firmware update)
  • Dolby Atmos with Dolby Atmos Height Virtualization (with future firmware update) and DTS:X
  • Wi-Fi , AirPlay 2 , Spotify Connect and Voice Control
  • MusicCast multi-room audio app control
  • Pandora , Spotify, Amazon Music, SiriusXM, TIDAL, Deezer, Napster and more
  • YPAO automatic room calibration with R.S.C. and Multi-Point
  • Phono input
  • MusicCast Surround-capable: add optional MusicCast speakers to provide wireless surrounds for a 5.1-channel setup

Dolby Atmos and Dolby Atmos Height Virtualization*

Feel every dimension in Dolby Atmos. Enjoy a 5.1 surround speaker system and two additional overhead speakers or two Dolby Atmos elevation speakers, delivering dramatic overhead effects for truly enveloping audio.

For those without in-ceiling or upward firing speakers in their system, Dolby Atmos Height Virtualization* technology can simulates the Atmos experience. Configure up to five speakers to replicate the effect of two in-ceiling speakers, or utilize all seven channels to simulate the powerful effect of four overhead speakers.

* Dolby Atmos Height Virtualization is available via a future firmware update

DTS:X
DTS:X immersive audio formatting places sound where it would naturally occur in space, creating life-like, multi-dimensional audio. The included spatial remapping engine of DTS Neural:X offers improved immersion and heightened realism in all your favorite movies.

CINEMA DSP 3D
This unique Yamaha proprietary sound field creation technology was created by combining measured sound field data with digital signal processing. Yamaha collected sound field data from famous concert halls and music clubs around the world, utilizing its wealth of experience in the fields of concert hall design, public address and mixing. By digitizing this vast trove of information and incorporating it into dedicated LSI devices, it effectively reproduces the spaces of concert halls and music clubs in your home. Immerse yourself in the astounding realism of your movies and enter a world of profound theater sound.

Compressed Music Enhancer
When music is encoded into a digitally compressed format like MP3, the frequency response suffers. The Yamaha Compressed Music Enhancer employs sophisticated digital signal processing using exclusive algorithms to restore what was lost, so the music always sounds the way it should.

HDR and HDR10+*
HDR (high dynamic range) video provides incredible contrast, smooth tone and rich, bright colors giving you full, high-definition enjoyment with an exceptionally realistic and natural picture quality.

HDR10+ greatly improves dynamic range (the ratio of light to dark) of video content on a scene-by-scene (or even frame-by-frame) basis. Also, using frame-by-frame metadata, it improves the scene characteristics between bright and dark so that important detail can remain. This enables displays to reproduce images more realistically, adhering to the creator's intent.

* HDR10+ is available via a future firmware update

4K/60Hz, 8K/60Hz* and 4K/120Hz*
Supports end-to-end 8K/4K resolutions and higher refresh rate solutions with a single upgraded cable for seamless integration within the HDMI eco-system. 8K delivers a super-immersive viewing experience with 2x the horizontal and vertical resolution of 4K, and 4 times as many pixels; and combined with 60Hz refresh rate enables smooth and sharp viewing of content with high-speed action. 4K/120Hz enables ultra-fast motion UHD images to be crisp and razor sharp; allowing sports, action movies, high-performance gaming and VR to benefit significantly.

* 8K/60Hz and 4K/120Hz are available via a future firmware update

Enhanced Media and Gaming (ALLM, VRR, QMS, QFT)*
Enhanced media and gaming features ensure an added level of smooth and seamless motion and transitions for gaming, movies and video. They include: Auto Low Latency Mode (ALLM), which enables the ideal latency setting to automatically be set allowing for smooth, lag-free and uninterrupted viewing and interactivity; Variable Refresh Rate (VRR) reduces or eliminates lag, stutter and frame tearing for more fluid and detailed gameplay; Quick Media Switching (QMS) for movies and video eliminates the delay that can result in blank frames before content is displayed; and Quick Frame Transport (QFT), which reduces latency for smoother, no-lag gaming and real-time interactive virtual reality.

* These features are available via a future firmware update

Specs

Amplifier Section

Channels 7.2
Rated Output Power (20Hz-20kHz, 2ch driven) 100 W (8 ohms, 0.06% THD)
High Slew Rate Amplifier Yes
Rated Output Power (1kHz, 1ch driven) -

Surround Sound Processing

Surround:AI N/A
Cinema DSP Yes
DSP Programs 17
Dialog Level Adjustment Yes
Virtual Presence Speaker Yes
Virtual Surround Back Speaker Yes
Dialogue Lift Yes
SILENT Cinema / Virtual Cinema DSP Yes
Dolby Atmos Yes
Dolby Atmos Height Virtualization Yes (via firmware update)
Dolby TrueHD Yes
Dolby Digital Plus Yes
Dolby Surround Yes
DTS:X Yes
DTS-HD Master Audio Yes
Auro 3D N/A

Audio Features

File Format MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
Pure Direct Yes
Compressed Music Enhancer Yes
High-resolution Music Enhancer N/A
YPAO Multi-point Measurement Yes
YPAO Volume Yes
Adaptive DRC (Dynamic Range Control) Yes
Initial Volume and Maximum Volume Setting Yes
A.R.T. Wedge N/A
Bi-amp Capability Yes
Audio Delay Yes (0-500 ms)
DA Converter 384 kHz / 32-bit BB PCM5102A

Video Features

HDMI eARC Yes
HDMI Audio Return Channel Yes
HDMI Pass-through 4K/60Hz, 8K/60Hz*, 4K/120Hz* (*via firmware update)
HDMI Upscaling Yes up to 4K
HDMI Up-conversion N/A
HDR 10+ Yes (via firmware update)
VRR/ALLM/QMS/QFT Yes (via firmware update)
Video Adjustment N/A

Connectivity

MusicCast Surround Yes
Wi-Fi Yes (2.4 / 5 GHz)
AirPlay Yes (Airplay 2)
Bluetooth Yes (SBC / AAC)
Phono Input Yes
XLR Terminal N/A
Component Video Input/Output N/A

Extensive Connections

HDMI Input/Output 07/01/20
HDMI CEC Yes
USB Input Yes
Network Port Yes
Front AV Input USB
Digital Audio Input / Output: Optical 01/01/00
Digital Audio Input / Output: Coaxial 01/01/00
Analog Audio Input / Output 04/01/00
Composite Video Input / Output N/A
Preout 2.2-ch
Headphone Output 1

Tuner Section

FM / AM Tuner Yes
User Interface On-Screen Display Graphical User Interface
SCENE Yes (8 sets)
App Control Yes (iPhone / iPad / Android phone / tablet)
Web Browser Control Yes
Remote Control Unit Yes

Zone Control

Zone 2 Audio Output Preout
Zone 3 Audio Output N/A
Zone 4 Audio Output N/A
Powered Zone Zone 2
Zone Video Output N/A
Zone B Output N/A
Zone GUI N/A
RS-232C Interface N/A
+12V Trigger Output 1
Remote (IR) Input/Output N/A
Party Mode Yes

General

Standby Power Consumption (IR only) 0.1 W
Auto Power Standby Yes
ECO Mode Yes
Dimensions (W x H x D) 17-1/8" W x 6-3/4" H x 14-7/8" D (with antenna up:17-1/8" W x 9-5/8" H x 14-7/8" D)
Weight 21.6 lbs.
