The numbers represent the number of speaker channels and subwoofers the A/V receiver supports. For example, a 7.2 channel A/V receiver will power up to 7 speakers and up to 2 subwoofers. If an A/V receiver supports Dolby Atmos, the channels may read out 7.2.4. In this format, once again 7 speakers are supported, along with up to 2 subwoofers. In addition, 4 Dolby Atmos height channels are supported for a total of 11 total speakers and 2 total subwoofers.
You can connect a powered subwoofer using a single RCA cable from the receiver’s SUB OUT / LFE jack to the subwoofer’s LINE IN. If the A/V receiver has a single SUB OUT and you wish to connect 2 subwoofers, you can do so using a RCA Y-splitter adapter.
If an A/V receiver lists a wattage rating of 150 watts at 8 ohms, this is how much power or wattage will be in total when only the main 2 channels are connected (front left and right speakers). The more speakers that are connected to the A/V receiver, the total wattage per speaker will drop as they all share the same power supply. Typically, with all speakers being played simultaneously, output in wattage to each speaker is around 60-70% of the 2 channel rating.
We recommend using banana connectors to connect to your A/V receiver if it has binding posts. This will provide a secure and reliable connection.
If an A/V receiver supports 2 zones, this means that addition to your main zone, you can connect a second stereo zone typically in another room or outdoors. You can play two different source of music for each zone or play the same source simultaneously for both zones. On the rear panel of the A/V receiver, you will see "Assignable" labels for the terminals you will be able to connect zone 2 speakers to and in the A/V receiver setup menu, you will be able to assign them.
Stereo receivers handle two-channel audio (left and right) for music listening and some also have HDMI output to connect to TV. A/V receivers handle multichannel sound (like 5.1 or 7.1 surround) and video switching for home theaters.
!
