Yamaha TT-N503 MusicCast Vinyl 500 Wi-Fi Turntable

by Yamaha
UPC: 027108957876
$699.95

SKU TT-N503Black
Color: Black

Product Qualifies for FREE Ground Shipping

Yamaha TT-N503 MusicCast Vinyl 500 Wi-Fi Turntable

Vinyl Unleashed. Stream your records and music services to MusicCast speakers with no wires attached and no receiver required. Wi-Fi connection ensures exceptional sound quality. With a MusicCast multi-room system, hear your records throughout your entire home.
  • Create a stereo system with MusicCast wireless speakers. Place the turntable and speakers wherever you want!
  • Expand to a multi-room audio setup by syncing with MusicCast wireless speakers in other rooms.
  • Stream music services with Wi-Fi , Bluetooth , AirPlay or Spotify Connect.
  • Yamaha Hi-Fi quality built for accuracy and sonic purity. Perfect for the audiophile or beginner vinyl collector.
  • Built-in phono preamp gives you flexibility to connect any audio system, adding streaming service playback to your legacy Hi-Fi system.

  • Turning the tables on cables

    Giving an 'old-school' medium a modern spin, wirelessly connect the MusicCast VINYL 500 turntable to your MusicCast speakers and other devices to enjoy your record collection without all the cables.

    Don t stop the music

    Hit the end of a record and don t want the music to stop With the VINYL 500 you can keep the music going by streaming from your music services via Wi-Fi, AirPlay or Spotify Connect.

    Connect the MusicCast VINYL 500 to your existing stereo equipment and get ready for a serious upgrade to your setup.

    Here, there and everywhere

    Leave the room and let your music follow. Featuring MusicCast multi-room technology, share and listen to your record collection throughout the house.

    Stream your vinyl collection to a range of MusicCast devices everything from speakers to sound bars.

    Anyway you want it

    Take control of your music streaming and your wireless setups with the MusicCast app. Create favorites, control your multi-room vinyl experience or MusicCast Stereo system. Geek out on all the options and settings to really make your music yours.

    You spin me 'round

    Turn your listening experience on its head. Meet the MusicCast VINYL 500.
    Meticulously designed to ensure the most faithful reproduction of sound - the way music was made to be heard the MusicCast VINYL 500 features a straight tonearm for an open sound as well as a belt-drive motor to minimize noise caused by vibrations.

    You turn me on

    The piano black finish shows off your style and your records. And with no receiver or speaker wires needed, get creative and put your VINYL 500 anywhere it looks good!

    Speak to me

    Voice control completes the picture when it comes to the turntable of the future.
    Connect to Amazon Alexa for effortless, hands-free control of your music streaming and multi-room setup.

    Specs
    Network
    • File format: Mp3/WMA/MPEG-4 AAC: Up to 48kHZ/16-bit, ALAC: Up to 96kHz/24-bit, FLAC/WAV/AIFF: Up to 192kHz/24-bit, DSD: Up to 11.2MHz
    • Ethernet: Yes
    • Wi-Fi: Yes (2.4/5GHz)
    • AirPlay: Yes

    Bluetooth
    • Version/profile: Version 4.2/A2DP, AVRCP
    • Audio codec: SBC, AAC
    • Maximum communication range: 10m/32.8 feet, 10 inches (without interference)

    Turntable
    • Drive method: Belt drive
    • Motor: DC motor
    • Rotation speed: 33 1/3 RPM, 45 RPM
    • Rotation speed variation: 2%
    • Wow and flutter: 0.2%
    • Platter: Aluminum diecast (diameter 30 cm)
    • Output level: 450mV (-7dBV, with RIAA EQ, 1kHz, 3.54cm/sec), 2.5mV 3dBV (without RIAA EQ, 1kHz, 3.54cm/sec)
    • Signal-to-noise ratio: 67dB or higher (A-weighted, 20kHz, LPF)

    Tonearm
    • Tonearm: Static balance straight tonearm
    • Effective arm length: 223.5mm
    • Overhang: 19mm
    • Stylus pressure adjustment range: 0 - 4g
    • Acceptable cartridge weight: 15.5 - 19g (including headshell)

    Attached Cartridge
    • Cartridge type: MM type
    • Output voltage: 2.5mV (1kHz, 3.54cm/sec)
    • Stylus pressure: 3.5 0.5g
    • Cartridge weight: 5.0 0.3g
    • Cartridge height: 17 0.7mm
    • Headshell weight: 10g

    Audio
    • Output terminal: RCA 2 (phono, line)
    • Output level: 2.0 0.3V (1kHz, 0dB, Fs 44.1kHz)
    • Signal-to-noise ratio: IHF-A network 110dB or higher (Infinity zero, Fs 44.1kHz)
    • Dynamic range: 100dB or higher (1kHz, -60dB, Fs 44.1kHz)
    • Harmonic distortion: 0.003% or lower (1kHz, 0dB, Fs 44.1kHz)
    • Frequency response: Fs 44.1kHz; 2Hz to 20kHz (+0/-3dB), Fs 48kHz; 2Hz to 24kHz (+0/-3dB), Fs 96kHz; 2Hz to 48kHz (+0/-3dB), Fs 192kHz; 2Hz to 96kHz (+0/-6dB)

    General
    • Power consumption: 6W
    • Eco-standby (reference date): 0.3W
    • Standby power consumption
      • Network standby ON, Bluetooth standby OFF, wired: 1.4W
      • Network standby ON, Bluetooth standby ON/OFF, Wi-Fi: 1.8W
      • Network standby ON, Bluetooth standby ON, wired: 1.6W
    • Dimensions (W x H x D): 17 3/4" x 5 3/8" x 14 1/2"
    • Weight: 12.6 lbs.
