Impedance: 4 ohms
RMS Watts: 150
PEAK Watts: 300
Frequency Response: 20Hz to 20KHZ
Sensitivity: 90db at 1watt / 1meter
Mid Bass: 6x9 EFG cone woofer with polyurethane surround
High Frequency: Pro-Axial Driver. Coaxially mounted titanium
diaphragm high output horn loaded compression driver
Size & Weight
Weight: 7 lbs (3.17kg)
Sealed Box: N/A
Diameter: 10.26 inches w/grill (260.40 mm)
Mounting Depth: 6.75 inches (171.45mm) with Crossover
Mounting Depth: 5.50 inches (142.24mm) without Crossover
Hole Cut Out: 8.47 inches(215mm) x 5.59 inches (142mm)
see user manual for more details
Note:
All specifications are for each REV696RS
!
