Wavtech link750.1plus 750 Watt Mono Amplifier

Brand: Wavtech | SKU: link750.1plus | UPC: 700987201543

Sale price
$399.95
Regular price
$499.95
You save
20%
Taxes calculated at checkout

Have a question?

If your system requires a 1 ohm stable amplifier, but doesn’t need the power of link1500.1plus, the link750.1plus is the solution. Utilizing our proprietary Dual Rail Voltage Power Supply, the amp produces the same power output at either 2 or 1 ohm. During installation, select the impedance that matches your subwoofers using the 4/2 or 1 ohm switch and the amp does the rest.

The link750.1plus can handle up to 40V and has our adaptive loading technology for OEM systems. It is also compatible with OEM start/stop systems. The bassFREQ preamp has a 24dB per octave crossover, adjustable parametric EQ and 24dB per octave subsonic filter for the best subwoofer tuning possible. It is compatible with the optional linkRC remote control.

Specs

750 Watt Mono Amplifier

400 watts x 1 @ 4 ohms

750 watts x 1 @ 2 ohms

750 watts x 1 @ 1 ohm

Small Footprint Only 10.25”x5.5”x1.65”

Dual Rail Voltage Power Supply

Fully Adjustable Parametric EQ

Variable Low-Pass Crossover (-24dB/oct)

Variable Subsonic Filter (-24dB/oct)

Remote Level Control (RLC) w/Optional linkRC

bassFREQ Bass Processor w/Parametic EQ

Active Thermal Management

Start/Stop System Compatible

Adaptive OEM Load Technology

40V Input Capability

Differential Balanced Inputs

Variable Gain Adjustment w/Clip LED

Auto Turn-On via DC-Offset or Audio Signal Detect

Locking Detachable Hi-Level Speaker Terminals

4 Gauge Power/Ground Terminals

Professional Grade Panel Mount RCA’s

Compact Aluminum Chassis w/Detachable Mounting tabs

link750.1plus Specifications

Input Sensitivity

SPK --------------------------- 1-20Vrms, 2-40Vrms

RCA --------------------------- 0.2V-5Vrms, 0.4V-10Vrms

Max Input Voltage (SPK) ------ 40Vrms

Frequency Response ----------- <10Hz to >500Hz (=0/-3dB)

THD+N ------------------------------- <1% at rated power

S/N ------------------------------------- >78dBA (1W, 4Ω)

Brand Wavtech
