Wavtech link500.4mini Compact 500 Watt 4 Channel Amplifier

Brand: Wavtech | SKU: link500.4mini | UPC: 700987201475

Sale price
$449.95
Regular price
$549.95
You save
18%
Taxes calculated at checkout

Have a question?

A pair of new front speakers and a subwoofer is one of the most common aftermarket audio upgrades. The link500.4mini is the perfect amplifier for this application. When used in 3-channel mode, the amplifier can produce 125 watts x 2 for the main speakers and 250 watts x 1 for the subwoofer, so it won’t lack for power. Speaking of the subwoofer, channels 3/4 have a 1-band PEQ, a subsonic filter and the ability to add an RLC to fine tune the subwoofers performance.

The link500.4mini has our new adaptive loading technology plus the ability to handle up to 40V of hi-level input. It also has fully adjustable high and low pass crossovers. For factory audio systems where no full-range signal is present, the link500.4mini has built-in summing, so it can handle that internally, without the need for an outboard processor. Like all Wāvtech amplifiers, the link500.4mini is start/stop system compatible.

Specs

500 Watt 4-Channel Amplifier

75 watts x 4 @ 4 ohms

125 watts x 4 @ 2 ohms

250 watts x 2 @ 4 ohms BTL

Small Footprint Only 9.2”x4.5”x1.65”

Adjustable Paragraphic EQ (Channels 3/4)

Variable Subsonic Filter (Channels 3/4)

Variable Hi/Low Pass Crossover (-12dB/oct)

Remote Level Control (RLC) w/Optional linkRC (CH 3/4)

Built-In Summing w/Level Trim Adjsutment

Parametric EQ (CH 3/4)

Active Thermal Management

Start/Stop Sytem Compatiable

Adaptive OEM Load Technology

40V Input Capabilty

Differential Balanced Inputs

Variable Gain Adjustment w/Clip LED

Auto Turn-On via DC-Offset or Audio Signal Detect

Locking Detachable Hi-Level Speaker Terminals

4 Gauge Power/Ground Terminals

Professional Grade Panel Mount RCA’s

Compact Aluminum Chassis w/Detachable Mounting tabs

lin500.4mini Specifications

Input Sensitivity

SPK --------------------------- 1-20Vrms, 2-40Vrms

RCA --------------------------- 0.2V-5Vrms, 0.4V-10Vrms

Max Input Voltage (SPK) ------ 40Vrms

Frequency Response ----------- <10Hz to >43kHz (+0/-3dB)

THD+N ------------------------------- <1% at rated power

S/N ------------------------------------- >85dBA (1W, 4Ω)

Brand Wavtech
