Wavtech link500.1mini Compact 500 Watt Mono Amplifier

Brand: Wavtech | SKU: link500.1mini | UPC: 700987201499

Sale price
$349.95
Regular price
$449.95
You save
22%
Taxes calculated at checkout

Have a question?

The link500.1mini amplifier was engineered from the ground up to be the best possible option for adding bass to any system. The speaker level input can handle up to 40V and features our adaptive loading technology, while the RCA input accepts up to 10V, making it the perfect solution for both factory and aftermarket head units. The link500.1mini produces 500 watts RMS @ 2ohms, and its incredibly small size means it will fit almost anywhere.

The link500.1mini utilizes Wāvtech’s proprietary bassFREQ preamp. It features a 24dB per octave crossover, adjustable parametric EQ and a subsonic filter, providing the fine tuning required to get the best out of any subwoofer. Like all Wāvtech amplifiers, the link500.1mini is compatible with start/stop systems. The optional linkRC remote provides for even more system control.

Specs

500 Watt Mono Amplifier

300 watts x 1 @ 4 ohms

500 watts x 1 @ 2 ohms

Small Footprint Only 9.2”x4.5”x1.65”

Fully Adjustable Parametric EQ

Variable Low-Pass Crossover (-24dB/oct)

Variable Subsonic Filter (-24dB/oct)

Remote Level Control (RLC) w/Optional linkRC

bassFREQ Bass Processor w/Parametic EQ

Active Thermal Management

Start/Stop System Compatible

Adaptive OEM Load Technology

40V Input Capability

Differential Balanced Inputs

Variable Gain Adjustment w/Clip LED

Auto Turn-On via DC-Offset or Audio Signal Detect

Locking Detachable Hi-Level Speaker Terminals

4 Gauge Power/Ground Terminals

Professional Grade Panel Mount RCA’s

Compact Aluminum Chassis w/Detachable Mounting tabs

link500.1mini Specifications

Input Sensitivity

SPK --------------------------- 1-20Vrms, 2-40Vrms

RCA --------------------------- 0.2V-5Vrms, 0.4V-10Vrms

Max Input Voltage (SPK) ------ 40Vrms

Frequency Response ----------- <10Hz to >500Hz (=0/-3dB)

THD+N ------------------------------- <1% at rated power

S/N ------------------------------------- >81dBA (1W, 4Ω)
