Shanling EH1 Desktop Headphone Amplifier and DAC

Brand: Shanling | SKU: EH1Black | UPC: 6972835392732

Sale price
$169.99
Regular price
$229
You save
26%
Taxes calculated at checkout

Color: Black

Have a question?
Shanling EH1 Desktop Headphone Amplifier and DAC - Safe and Sound HQ

Shanling EH1 Desktop Headphone Amplifier and DAC

Color: Black

Sale price
$169.99
Regular price
$229

More powerful than UA Dongles, simpler than H Portable DAC/AMPs, smaller than the EH3, that’s the new line of compact desktop DACs & Amplifiers from Shanling. Meet the new Shanling EH1

Shanling EH1 is probably the simplest device we released in recent memory. No screens, no complicated systems, just a simple curved aluminium body, two headphone outputs and few wheels and buttons. Powered by either USB-C or 5V DC, its Cirrus Logic DAC and SGM amplifiers provide fast and clean sound, that can be easily adjusted with the dedicated Treble & Bass controls. Then add to it SPDIF coaxial Out and Line-Out/Pre-Out to get a great sounding and powerful little package.

Shanling EH1 Key Features

-          Cirrus Logic CS43198 DAC

-          Dual SGM8262 Headphone Amplifiers

-          Up to 1015 mW @ 32 Ohm Output Power

-          Treble (+-10dB) & Bass (+-6dB) Tone Control

-          Hi-Res 32 bit / 768 kHz & DSD512

-          USB-C Digital Input

-          6.35mm & 4.4mm Headphone Outputs

-          RCA Output with switchable Line-out / Pre-out mode

-          SPDIF Coaxial Digital Output

-          Power by USB C or 5V DC Power

-          New Curved Design, Aluminium Construction

Brand Shanling
Model EH1
DAC Chip Cirrus Logic CS43198
Signal to Noise Ratio (dB) RCA 116, 4,4mm Balanced 119
Coaxial/Optial Digital Inputs 0 / 0
RCA/XLR Outputs 1 / 0
Subwoofer Output 0
Headphone Amplifier Yes
Bluetooth No
Bluetooth No
Wi-Fi No
Bit Depth -USB (dB) 32
Mas Sampling Rate (USB) 768 kHz
Dimensions (H x W x D) 1.44" x 6.14" x 3.54"
Weight (lbs) .86
Warranty 1 Year

Compare with similar items

Shanling EH1 Desktop Headphone Amplifier and DAC - Safe and Sound HQ

This item Shanling EH1 Desktop Headphone Amplifier and DAC

Black
Cambridge Audio DacMagic 200M Digital to Analog Converter and Headphone Amplifier - Safe and Sound HQ

Cambridge Audio DacMagic 200M Digital to Analog Converter and Headphone Amplifier

Luxsin Audio X8 Intelligent DAC and Headphone Amplifier - Safe and Sound HQ

Luxsin Audio X8 Intelligent DAC and Headphone Amplifier

Shanling EH2 R2R DAC and Headphone Amplifier Open Box - Safe and Sound HQ

Shanling EH2 R2R DAC and Headphone Amplifier

Price
$169.99
$399.00
$699.00
$279.99
Rating
1
Brand
Shanling
Cambridge Audio
Luxsin Audio
Shanling
Model
EH1
DacMagic 200M
X8
EH2
DAC
Cirrus Logic CS43198
2x ESS Sabre ES9028Q2M
8x Cirrus Logic CS43198 DAC
In-house 24-bit discrete R2R DAC module
Signal to Noise Ratio (dB)
RCA 116, 4,4mm Balanced 119
115
> 124 (RCA), > 129 (XLR), > 123 (Headphone Output)
RCA 119, 4,4mm Balanced 119
Coaxial/Optical Digital Inputs
0 / 0
2 / 2
1 / 1
1 / 1
RCA/XLR Outputs
1 / 0
1 / 1
1 / 1
1 / 0
Subwoofer Output
0
0
No
0
Headphone Amplifier
Yes
Yes
Yes
Yes
Bluetooth
No
Yes
Yes
No
Wi-FI
No
No
Yes
No
Bit Depth (SPDIF)
24
24
24
Max Sampling Rate (SPDIF)
192 kHz Coaxial / 96 kHz Optical
192 kHz
192 kHz
Bit Depth (USB)
32
32
32
32
Max Sampling Rate (USB)
768 kHz
768 kHz
768 kHz
768 kHz
Dimensions (HxWxD)
1.44" x 6.14" x 3.54"
2 1/4" x 8 1/2" x 9 1/2"
2.52" x 9.29" x 9.32"
1.44" x 6.14" x 5.91"
Weight (lbs)
.86
2.718
6.06
1.57
Warranty
1 Year
3 Years
1 Year
1 Year
