Ortofon LH-9000 Carbon Fiber Headshell

by Ortofon
UPC: 4571106661656

SKU LH-9000

Product Qualifies for FREE Ground Shipping

  • Ortofon LH-9000 Carbon Fiber Headshell

    Ortofon LH-9000 headshell
    Exceptionally high quality carbon fiber headshell, the LH-9000 is made using carbon fiber resin for the elimination of unwanted resonances. The LH-9000 is perfect for a variety of high-end cartridges, e.g. Cadenza Series, MC A95, MC Anna Diamond, MC Anna and MC Windfeld Ti.

    The LH-9000 comes with leadwires for easy and convenient connection
    All Ortofon cartridges have a colour coding of the terminals, indicating red and green for right channel respectively hot and ground terminal. White and blue for left channel respectively hot and ground terminal. Green terminal will always be used for grounding the cartridge housings or motor-system, whenever connected inside the cartridge.

    We recommend to connect lead wires to the cartridge and headshell before mounting the cartridge on the headshell.

    Please remember correct orientation of the leads. Ortofon cartridges' terminal PINs diameter is 1.2 mm, whilst Ortofon headshells' PINs diameter is only 1.0 mm.


    Features and Technical data

    • Universal mount
    • Magnesium with carbon fiber
    • High Purity Copper headshell leads (LW-7N) included
    • Weight without screws - 16.8 grams
    • Mounting distance min. - 38.1 mm
    • Mounting distance max. - 44.9 mm
    • Headshell length - 52.0 mm
    • Headshell width -  20.0 mm
