Click to open expanded view
Enlarged magnet circuit
To realize clear sound
Only 1/8"of mounting height
To fit for wider car selection
Specs
Electrical
Impedance (Ω) 4Ω
Peak Input Power (W) 220W
RMS Input Power (W) 21W
Sensitivity (dB at 1m) 88dB
Frequency Response (Hz) 50-18000Hz
Woofer
Diaphragm PP Silver
Size 100mm 4in
Surround Cloth
Magnet Ferrite φ70xt10
Dimension
Width 104.0 mm 4-1/8 in.
Height 104.0 mm 4-1/8 in.
Cutout Diameter Φ92.6 mm Φ3-5/8 in.
Tweeter Height 3.2 mm 1/8 in.
Mounting Depth 43 mm 1-11/16 in.
Weight
Weight of Speaker (pc) 369 g 0.8 lbs.
Weight of Woofer Magnet 160 g 5.6 oz.
Gross Weight 800 g 1.8 lbs.
Accessory
Screw sets Tapping Screw φ4x25*8pcs
Speed Nut 8pcs
Speaker Cord 0.3m*2pcs
Warranty Card 1pcs
Impedance (Ω) 4Ω
Peak Input Power (W) 220W
RMS Input Power (W) 21W
Sensitivity (dB at 1m) 88dB
Frequency Response (Hz) 50-18000Hz
Woofer
Diaphragm PP Silver
Size 100mm 4in
Surround Cloth
Magnet Ferrite φ70xt10
Dimension
Width 104.0 mm 4-1/8 in.
Height 104.0 mm 4-1/8 in.
Cutout Diameter Φ92.6 mm Φ3-5/8 in.
Tweeter Height 3.2 mm 1/8 in.
Mounting Depth 43 mm 1-11/16 in.
Weight
Weight of Speaker (pc) 369 g 0.8 lbs.
Weight of Woofer Magnet 160 g 5.6 oz.
Gross Weight 800 g 1.8 lbs.
Accessory
Screw sets Tapping Screw φ4x25*8pcs
Speed Nut 8pcs
Speaker Cord 0.3m*2pcs
Warranty Card 1pcs
Brand
Kenwood
