Kenwood KAC-D8105 Class D 5-Channel Power Amplifier
Product Qualifies for FREE Ground Shipping
Kenwood KAC-D8105 Class D 5-Channel Power Amplifier
- Max Power 1600W
- RMS 50W x4 + 300W (4Ω)
- RMS 75W x4 + 500W (2Ω)
- Size (inch) (W) 9" x (H) 2-3/16" x (D) 7-3/8"
- Variable High & Low Pass Filter
- Bass Boost
Expanded Frequency Response
Supporting Hi-Res Audio, KAC-D8015 is ideal for high resolution audio playback as it features a frequency response that extends to 50kHz.
Dual Sigma Drive
This advanced negative feedback circuit improves damping factor and increases accuracy and sound quality. When a signal is passed to a subwoofer, like a 50Hz note, the speaker will move and create the note. However, because the speaker has mass and a suspension, it won't stop moving once it's in motion. This extra movement (sound) creates a type of distortion that's not part of the original signal. The negative feedback circuit senses this unwanted movement and sends out an opposite pulse to stop the speaker like an electronic brake.
Specs
MAX POWER 1600W
RMS POWER OUTPUT (4Ω) 50W x 4 + 300W
RMS POWER OUTPUT (2Ω) 75W x 4 +
RMS POWER OUTPUT Bridged 150W x 2 (Bridged) + 300W
Features: Speaker Level Input, Signal Sensing Turn-On, Variable High Pass Filter , Variable Low Pass Filter, Bass Boost
Dimensions (W)9” x (H)2-3/16” x (D)7-3/8”
Weight 4.5 lbs (2.0kg)
