Audison bit Tune DSP Auto Tuning and Analyzer

Brand: Audison | SKU: bit Tune | UPC: 8018823110631

Price
$1,299.99
Taxes calculated at checkout

Have a question?

Sound Tuning Tool Suite
The Audison bit Tune is a revolutionary system of automatic calibration for Audison bit processors developed with bit Drive technology. Bit Tune also includes a multitude of additional features for electro-acoustic verification and analysis of any car audio system. The Audison team s goal in developing the bit Tune was to speed up the setting of basic parameters for the calibration of the bit processors (time alignment, equalization, levels, etc.), ensuring an excellent level of acoustic performance. This phase also includes the diagnosis of comm on errors (channel inversion/phase, no signal on one channel/cable, etc.) to set the specialist free from his routine work and allow him to focus on the art of fine-tuning. Only personal interpretation and experience can achieve what a machine could never do: create Your Sound!

AUTO PROCESSOR SETUP: the automatic calibration function includes: Auto EQ, Auto Time Alignment, and Level Check. Automatic setting of: time alignment, equalization curve and output levels of an Audison bit processor connected to the bit Tune. The Processor Auto Setup tool is used with an on-screen wizard, and can be used independently to carry out specific measurements.

SOURCE CHECK: takes electrical measurements of the Pre Out or Hi-Level outputs of the
connected source, displaying signal level. Using the spectrum analyzer function (Spectrum), the user can graphically assess if the source signal is equalized or not.
RTA - REAL TIME ANALYZER: measures the acoustic response of the audio system, considering the characteristics of the vehicle acoustics. Measurements are taken using the HSM microphone.

POLARITY CHECK: with this tool you can check the electrical phase of the speakers installed in the audio system.

OSCILLOSCOPE: includes the following tools: Voltmeter, Power Meter, Distortion and Spectrum. Thanks to these tools, it is possible to perform electrical measurements of the signal level and distortion of an inputted audio signal as well as the power of amplifiers. The result of the measurements is available in graphic and numeric formats.

GENERATOR: creates sinusoidal signals adjustable in frequency (20Hz-20KHz) and amplitude. A bandwidth limited, adjustable time sweep can also be generated. It also features a generator of Pink and White Noise used to measure acoustic response.
PLAYER: a software tool used for the playback of music formats *.wav, *.Wma, *.mp3, *.flv, *.flac. Capable of handling up to 24bit/192kHz resolution files.

BATTERY SCOPE: implements an oscilloscope in DC, specifically calibrated to measure the
vehicles’ battery voltage found during vehicle start-up or audio system demands. This tool can detect immediate voltage drops which a common volt meter can’t detect.

OPTICAL CABLE TEST: checks if signal is present on sources with S/PDIF optical output and provides the ability to analyse the digital bit rate and sampling frequency of the signal; audio can be heard through the built-in speaker of the bit Tune.

CREATE REPORT: automatically creates a report (in PDF format) with information concerning: the technician, the client, the vehicle, obtained measurements and the adjustments made through the Processor Auto Setup.

LOAD SIMULATOR: allows the user to check if the OEM source unit or amplifier requires a load (speaker connected) on the speaker leads to output audio. The check is performed by the bit Tune by applying a resistive or inductive load. Once the check has been performed, a similar load has to be connected to the OEM source outputs, to then connect an amplifier or a processor to the source.

HI-LEVEL ART TEST: checks if the Hi-Level outputs of the OEM source are compatible and capable of working with ART (Automatic Remote Turn On) equipped processors and/or amplifiers.

LINE NOISE ANALYZER: checks if there is audio signal and possible noise disturbances along the analogue or optical digital audio line. The check is confirmed by listening to the signal on the built-in speaker of the bit Tune.

ELECTROMAGNETIC SNIFFER TEST: with the EMS probe placed on or near electrical parts or wiring of the vehicle, you can acoustically identify the source of electromagnetic (radiated noise) disturbance using the built-in speaker of the bit Tune



Brand Audison
