Power Amplifier Rated output 100 W+100 W (6 Ω/ohms, 1 kHz, T.H.D. 0.7 %)
70 W + 70 W (8Ω/ohms, 20 Hz 20 kHz, T.H.D. 0.05%)
Impedance 4 – 16 Ω/ohms
Input sensitivity/Input impedance 150 mV/47 kΩ/kohms
Total Distortion ANALOG IN: 0.1 %(1 kHz)
S/N ratio (10 W, 6 Ω/ohms, IHF-A) ANALOG IN:
83 dB (IHF–A weighted)
Frequency response 20 Hz to 20 kHz : ±1.5 dB
Music Services Supported Pandora, Spotify, TuneIn, Napster, SiriusXM, Amazon Music, Tidal, iHeartRadio, Deezer, Mood:Mix and SoundCloud with more coming soon.
Subject to availability in your area.
Music Stored On Phone/Tablet iTunes music stored locally on your iOS device or music files on your Android or Kindle Fire device.
NAS (Network Attached Storage) Play from your home network: DLNA compliant.
USB Storage Connected to the HEOS Amp or other HEOS player. Aux Input: Analog or optical digital sources connected to the HEOS Amp or other HEOS players.
Music Downloads DRM-free downloads from any service.
Subject to audio format support.
Internet Radio Supported Streaming AAC, MP3, WMA (via the TuneIn service).
Album Art Supported JPG, PNG, BMP and GIF picture formats.
Audio Formats Supported Audio Formats Supported:
WMA: Up to and including 192kbps
AAC and MP3: Up to and including 320kbps
WAV, ALAC and FLAC: Up to and including 24-bit/192kHz.
DSD: 2.8MHz, 5.6MHz
Bluetooth Supported Play on one speaker or add other HEOS speakers in party mode.
Aux Input Analog or optical digital sources connected to the HEOS Amp or other HEOS players.
Wireless Connectivity Supports latest dual band wireless networks (including 802.11 a/b/g/n/ac standards).
Wired Connectivity Single RJ-45 jack for connection to wired Ethernet
Power Supply AC 120 V, 60 Hz
Operating Temperature Range 41°F to 95°F
Package Contents HEOS Amp
3.5mm setup cable
Quick Start Guide
Buttons and Indicators Volume up/down
Mute / Mute button LED indicator
Multicolored LED status indicator
Network ‘connect’ button (rear)
Bluetooth ‘connect’ button (rear)
Dimensions (H x W x D) 3.7in x 8.74in x 8.43in
Product Finish Gunmetal Silver front, top and back panels with black sides.
